Kobold KSV Series - Technical Information; Material Combinations

KSV
KSV K05/0322 page 5
7. Technical Information
Connection: 1/8” NPT female
Option:
hose connector, Ø 8 mm, polyamide
straight version (order no. ...G)
angle version (order no. ...W)
plastic compression fitting (order no. ...K)
Inlet & outlet: horizontal
Measuring accuracy: ± 6 % of full scale value
Repeatability: 1 % of full scale value
Operating pressure: max. 6.0 bar (device is not suitable for vacuum
pressure)
Operating temperature: polysulfone: - 20 °C...+ 120 °C
Material combinations
Housin
g
Connection O-rin
g
s
III Pol
y
sulfone Brass, nickel-plated NBR
I
V
Pol
y
sulfone St. steel, 1.4305 FPM
