KSV
page 6 KSV K05/0322
8. Order Codes
Order details (Example: KSV 1404 L, material combination IV (PSU, VA) with
control valve. Meas. range 50 – 150 Nl/h air)
Water Float with control valve
material combination
without control valve
material combination
Air
(Add suffix
“..L” to code)
L/h III IV III IV Nl/h*
0.25-1.5 Glass KSV 1301 KSV 1401 KSV 2301 KSV 2401 20-80
1-4 St. steel KSV 1304 KSV 1404 KSV 2304 KSV 2404 50-150
0.5-6 Glass KSV 1306 KSV 1406 KSV 2306 KSV 2406 50-300
2.5-15 St. steel KSV 1316 KSV 1416 KSV 2316 KSV 2416 50-500
5-30 Titanium KSV 1335 KSV 1435 KSV 2335 KSV 2435 0.35-1.5 Nm³/h
10-80 Hard metal KSV 1380 KSV 1480 KSV 2380 KSV 2480 0.5-2.4 Nm³/h
Option: hose connector, straight version item code. Suffix G / angle version item code.
Suffix W plastic coupling for PE and PP (polypropylene) piping ND 6 mm with box nut Suffix K.
*At 1.2 bar abs.; 20°C.
9. Dimensions
