Kodiak RC022 User Manual

Kodiak Recirculating Chiller Technical Manual
Manual # 820-0109, Rev. Y, 07/08/10 - 9 - Check Lytron’s website www.Lytron.com
for the most current technical information.
SPECIFICATIONS
1
RC006 RC009 RC011 RC022 RC030 RC045
Thermal Capacity
2
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
Watts
825
685
1,050
875
1,650
1,400
2,400
2,150
3,450
2,950
5,900
4,950
BTU/hr
2,800
2,330
3,585
2,988
5,780
4,760
8,755
7,310
12,070
10,030
20,230
16,830
115V~ 60Hz 1ph
G03 G03 G03 N/A N/A N/A
230V~ 50Hz 1ph
H03 H03 H03 H03 H03 H03
230V~ 60Hz 1ph
NA J03 J03 J03 J03 J03
Full Load Amps
3
G03
9.9 A 12.2 A 14.3 A --- --- ---
J03
--- 5.8 A 7.4 A 10.0 A 14.5 A 19.6 A
H03
4.5 A 5.3 A 6.3 A 9.5 A 13.7 A 17.2 A
Compressor Size
¼ Hp 1/3 Hp ½ Hp ¾ Hp 1 Hp 1 ½ Hp
Refrigerant Type
R134A R134A R134A R134A R134A R134A
Temperature
Stability
± 0.2°F
(0.1°C)
± 0.2°F
(0.1°C)
± 0.2°F
(0.1°C)
± 0.2°F
(0.1°C)
± 0.2°F
(0.1°C)
± 0.2°F
(0.1°C)
Operating
Environment
50°F to 95°F
(10°C to 35°C)
50° F to 95°F
(10°C to 35°C)
50°F to 95°F
(10°C to 35°C)
50°F to 95°F
(10°C to 35°C)
50°F to 95°F
(10°C to 35°C)
50°F to 95°F
(10°C to 35°C)
Coolant
Temperature
Range
4
41°F to 95°F
(5°C to 35°C)
41°F to 95°F
(5°C to 35°C)
41°F to 95°F
(5°C to 35°C)
41°F to 95°F
(5°C to 35°C)
41°F to 95°F
(5°C to 35°C)
41°F to 95°F
(5°C to 35°C)
Reservoir Capacity
1 gal (3.8 l) 1 gal (3.8 l) 2 gal (7.6 l) 2 gal (7.6 l) 6 gal (22.6 l) 6 gal (22.6 l)
Dimensions
5
Width
12.5" (318) 12.5" (318) 14.8" (376) 14.8" (376) 21.4" (543) 21.4" (543)
Depth
19.0" (483) 19.0" (483) 24.5" (622) 24.5" (622) 27.8" (705) 27.8" (705)
Height
22.0" (559) 22.0" (559) 26.5" (673) 26.5" (673) 31.0" (787) 31.0" (787)
Connection
½” FNPT ½” FNPT ½” FNPT ½” FNPT ½” FNPT ½” FNPT
Weight
97 lbs (44 kg) 100 lbs (45 kg) 122 lbs (55 kg) 166 lbs (75 kg) 260 lbs (118 kg) 270 lbs (123 kg)
Process Coolant
Delivery Pressure
Factory preset to 90 psig max (for PD and turbine pumps only)
1
Specifications are subject to change.
2
Capacity is for 20°C delivery water at a 20°C ambient.
3
Full load amperage for air -cooled models with standard pumps without the optional heater. Standard pumps are the BB
for the RC006, RC009, RC011, RC022 and BG for the RC030 and RC045. Contact Lytron for current draw of other models.
4
Chiller will shut down when coolant temperature reaches 10°C above the coolant temperature range.
5
Dimensions do not include filters or external valves.

Kodiak RC022 Specifications

General

Brand	Kodiak
Model	RC022
Category	Chiller
Language	English
