MJ400080F1
❑Model and diameter , flow range, connection
MODEL
DIAMETER
FLOW RANGE
FITTINGS
ＦＭ０１０１
Ｌ
LOW FLOW：0.5～4 L/min
R3/8(PT3/8 MALE)
ＦＭ０１０２
Ｍ
MIDDLE FLOW： 2～16 L/min
R1/2(PT1/2 MALE)
ＦＭ０１０３
Ｈ
LARGE FLOW： 4～40 L/min
R1/2(PT1/2 MALE)
ＦＭ０１０５
Ｈ
LARGE FLOW：10～150 L/min
EQUAL TO ESLON UNION 25A
ＦＭ０１０７
Ｈ
LARGE FLOW：25～250 L/min
R1
・
1/4（PT1
・
1/4 MALE）
３．Connection
