Kofloc FM01 Series User Manual

MJ400080F1
2. Standard Specifications
◼ Main specifications
Item
Specification
Current
Pulse
Indicator
Fluid
Pure water, industrial water (in conformity with tap water)
Material
Body: PPS, Cover: PBT
Output cord: conductor = tinned bare annealed copper wire,
sheath = heat-resistant/cold-resistant PVC
Accuracy
±3％F.S.
±3％F.S.
Current accuracy: ±3％F.S.
Indication accuracy: ±3％F.S.
±1digit
Reproducibility
±0.5％
Maximum working output
1MPa（10kgf/㎠）
Fluid temperature
0-70℃
Ambient temperature
0-50℃
Supply voltage
12VDC (or 24VDC)
Output
4-20ｍADC
Open collector
MAX.10mA/30V DC
FM0101: 800Hz@4L/m
FM0102: 800Hz@16L/m
FM0103: 584Hz＠40L/m
FM0105: 900Hz@150L/m
FM0107: 750Hz@250L/m
4-20ｍADC
Load resistance
0-250Ω (250 to 500Ω at 214VDC)
Time constant
1 second
Waterproofing
Splash-proofing structure (JIS C0920)
Cable length
2m terminated
(pre-tinning)
2m terminated
(pre-tinning)
3m terminated
(pre-tinning)
Weight
60g (main body)
165g (main body)
60g (main body)
165g (main body)
100g (main body)
205g (main body)
Caution in using
No excessive tightening torque should not be given to the main body and fitting screw because they are
made of resin.
