What to do if my Kohler 13.5EFKOZD bus is considered to be live?
Check the bus for any residual voltage, which can sometimes be induced by large transformers or motors. If residual voltage is present, you might need to adjust the Dead Bus Threshold to accommodate it.
What to do if my Kohler Portable Generator breaker is not charged?
Verify that the motor operator is receiving voltage at the appropriate contacts, allowing it to wind the spring.
What to do if my Kohler 13.5EFKOZD Portable Generator bus sensing is not connected?
Verify that the bus sensing wiring is connected to the load side of the motor-operated breaker for this generator.
How to fix intermittent connection in PGEN wiring in Kohler 13.5EFKOZD?
Confirm that there are no loose wiring connections or “whiskers” at the PGEN terminal blocks. Using “Fork”, “ring”, or “crow’s feet” connectors for terminal block connections is preferable.
How to fix CB trip relay wired as normally open in Kohler 13.5EFKOZD Portable Generator?
Check that the CB trip relay is wired to hold a trip on the breaker when the relay is not energized.
How to resolve PGEN wiring not connected correctly in Kohler Portable Generator?
Check the wiring. All PGEN + connections should be connected with daisy-chain wire (Belden #9841 or equivalent). Make sure terminations are at the end of the network and that there are no unintentional or loose connections.
How to resolve short circuit in communication wiring in Kohler 13.5EFKOZD?
In Controller Config --> Communication Setup, verify the PGEN Node ID is less than 16. If it is not, check the PGEN wiring for short circuits. Otherwise, further troubleshooting is needed.
How to resolve close is not applied to the circuit breaker in Kohler 13.5EFKOZD Portable Generator?
Check the wiring between the generator controller and the circuit breaker close coil. Also, check the close coil to ensure it is not defective.
How to resolve wiring to power is not complete in Kohler 13.5EFKOZD Portable Generator?
Connect the supply to the CB close relay to either 24V from wire #70 or an external 24VDC supply (with battery storage).
How to resolve breaker status feedback is not valid, no bus sensing in Kohler 13.5EFKOZD Portable Generator?
Verify the wiring on the circuit breaker to ensure it is connected correctly. Verify bus wiring for all nodes. Verify the generator output is connected to the line side of the generator breaker.
General| Model | 13.5EFKOZD |
|---|---|
| Type | Portable Generator |
| Fuel Type | Gasoline |
| AC Output | 120/240 V |
| Starting Watts | 13500 W |
| Running Watts | 12000 W |
| Starting System | Electric Start |
| Run Time at 50% Load | 10 hours |
| Maximum Output | 13500 watts |
| Rated Output | 12 kW |
| Outlet Types | 1x 120/240V 30A, 1x 120/240V 50A |
Provides detailed specifications for the engine, including type, bore, stroke, and capacity.
Identifies and lists features of the Decision-Makerr 3500 controller.
Describes the Decision-Makerr 3500 controller with an integrated voltage regulator.
Lists essential checks to perform before starting the generator set to ensure satisfactory operation.
Explains the different modes of operation for the generator set controller.
Describes the yellow FAULT lamp and alarm horn for warning faults that do not shut down the generator.
Explains the red FAULT lamp, alarm horn, and shutdown for critical fault conditions.
Explains how to access controller data via digital display or PC.
Groups generator set faults, probable causes, and recommended actions.
Troubleshooting steps for when the breaker fails to close to the bus.
Troubleshooting guide for various protective relays like reverse power and overvoltage.
Troubleshooting steps for issues related to the voltage regulator.
Details the controller service replacement kit and its installation procedure.
Explains how the controller provides voltage regulation and the role of the activator board.
Guides for troubleshooting alternator output conditions like no voltage, overvoltage, and fluctuating voltage.
Describes the process of matching generator output to the paralleling bus.
Details how real power output is controlled and shared.
Explains how reactive power output is controlled.
