TP-6953 7/1988 Section 2 Operation
SiteTecht Parameter
Write
Access
Units
Decision-Maker
r
3500
User Interface
Notes
Digital Input Status None The current value of the
input (scaled to the units
of the function ID)
Digital Input Enabled Always Enabled: On/Off Indicates whether this
input is enabled
Digital Input Logic Always Thetypeofswitchthatis
connected to the input,
where “normal” refers to
the non-activated state
Digital Input Function Always Function: Indicates the functionality
of this IO point
Digital Input Event Always Event: The parameter ID
defining the function for
this input
Digital Input Delay Always s Delay Time: ##s Thetimethattheinput
must be active before a
status change is
indicated
Digital Input Inhibit Delay Always s Inhibit Time: ##s Thetimethattheinput
must be active before a
status change is
indicated
Digital Input Description Alway s Description: A user-defined
description of this IO
point
Programmable Digital Input 112 (See Figure 2-22)
Digital Input Board Number None I/O Board N umber: X Indicates board number
this IO point is located on
Digital Input Io Number None Indicates the point
number, of this IO type
on this board, for this
configuration
Digital Input Status None The current value of the
input (scaled to the units
of the function ID)
Digital Input Enabled Always Enabled: On/Off Indicates whether this
input is enabled
Digital Input Logic Always Thetypeofswitchthatis
connected to the input,
where “normal” refers to
the non-activated state
Digital Input Function Always Function: Indicates the functionality
of this IO point
Digital Input Event Always Event: The parameter ID
defining the function for
this input
Digital Input Delay Always s Delay Time: ##s Thetimethattheinput
must be active before a
status change is
indicated
Digital Input Inhibit Delay Always s Inhibit Time: ##s Thetimethattheinput
must be active before a
status change is
indicated
Digital Input Description Alway s Description: A user-defined
description of this IO
point
Programmable Digital Input 113 (See Figure 2-22)
Digital Input Board Number None I/O Board N umber: X Indicates board number
this IO point is located on
Digital Input Io Number None Indicates the point
number, of this IO type
on this board, for this
configuration
Digital Input Status None The current value of the
input (scaled to the units
of the function ID)
Digital Input Enabled Always Enabled: On/Off Indicates whether this
input is enabled
