TP-6953 7/1990 Section 2 Operation
SiteTecht Parameter
Write
Access
Units
Decision-Maker
r
3500
User Interface
Notes
Digital Output Description Always Description: A user-defined
description of this IO
point.
Programmable Digital Output 116 NOTE: Tied to the CBC output (See Figure 2-22)
Digital Output Board Number None I/O Board Number: X Indicates board number
this IO point is located on
Digital Output Io Number None Indicates the point
number, of this IO type
on this board, for this
configuration
Digital Output Status None The value of the input
relative to the full range
of the input
Digital Output Enabled Always Enabled: On/Off Indicates whether this
input is enabled
Digital Output Logic Always Logic: Active On/Active Off Indicates whether
shutdown is active for
this input
Digital Output Function Always Function: Indicates the functionality
of this IO point
Digital Output Event Always Event: The parameter ID
defining the function for
this input
Digital Output Description Always Description: A user-defined
description of this IO
point.
Programmable Digital Output 117 NOTE: Tied to the RD4 output (TB13 pin 13) (See Figure 2-22)
Digital Output Board Number None I/O Board Number: X Indicates board number
this IO point is located on
Digital Output Io Number None Indicates the point
number, of this IO type
on this board, for this
configuration
Digital Output Status None The value of the input
relative to the full range
of the input
Digital Output Enabled Always Enabled: On/Off Indicates whether this
input is enabled
Digital Output Logic Always Logic: Active On/Active Off Indicates whether
shutdown is active for
this input
Digital Output Function Always Function: Indicates the functionality
of this IO point
Digital Output Event Always Event: The parameter ID
defining the function for
this input
Digital Output Description Always Description: A user-defined
description of this IO
point.
Programmable Digital Output 118 NOTE: Tied to the RD3 output (TB13 pin 12) (See Figure 2-22)
Digital Output Board Number None I/O Board Number: X Indicates board number
this IO point is located on
Digital Output Io Number None Indicates the point
number, of this IO type
on this board, for this
configuration
Digital Output Status None The value of the input
relative to the full range
of the input
Digital Output Enabled Always Enabled: On/Off Indicates whether this
input is enabled
Digital Output Logic Always Logic: Active On/Active Off Indicates whether
shutdown is active for
this input
Digital Output Function Always Function: Indicates the functionality
of this IO point
Digital Output Event Always Event: The parameter ID
defining the function for
this input
Digital Output Description Always Description: A user-defined
description of this IO
point.
To Next Page
