30 Section 1 Specifications TP-6953 7/19
1.13 Magnetic Pickup Sensor
(13- 24EKOZD/11- 20.5EFKOZD Models)
1
GM89507-
1. Magnetic pickup sensor
Figure 1 -11 Magnetic Pickup Sensor Location
Sensor
P/N
Resistance Operating Gap
GM92350
1kOhms±10% @ 20_C(68_C)
1 mm (0.039 in.)
Note: For 32/40EKOZD and 28/35EFKOZD models, consult the Engine Service Manual for speed sensor information. See the List of Related
Literature found at the beginning of this manual for the publication number.
