TP-6071 3/008 Section 2 Scheduled Maintenance
2.2 Lubrication System
The selection of engine oil is very important to a diesel
engine. If an unsuitable oil is used or an oil change is
neglected, it may result in damage and a shorter engine
life. Oil must meet the API classification of CD or CC.
Recommended SAE viscosity designation for given
temperature ranges is listed in Figure 2-1.
Note: Failure to observe these standards may cause
inadequate lubrication or oil pressure and cold
starting difficulties.
°C
°F
-- 3 0 -- 2 0 -- 1 0 0 1 0 2 0 3 0 4 0
0204060 80 100
°C
°F
5W20
20W40
10W30
20W20
20W30
20W40
TP-5856-1
SAE
Service
Grade
Operating Temperature
Figure 2-1 Engine Oil Selection
