Kohler 48RCLB/C

TP-7102 9/2136 Section 3 RDC2 Controller Operation
3.10 Generator Metering Menu
The generator metering menu displays the generator
voltage and frequency. See Figure 3-10.
Voltage Calibration
The voltage calibration mode can be entered from the
Generator Metering menu. Contact a Kohler-authorized
dealer for service.
The Reset Calibration menu allows you to set the
voltage reading back to the original value after
calibration, if necessary. See Figure 3-10.
Volts L1- L2:
240 V
Volts L2- L3:
240 V
Volts L3- L1:
240 V
Generator - - >
Metering
Reset
Calibration
<- - Return
Reset
Calib? No
Volts:
240 V
Three-phase
Single-phase
tp6810
Reset
Calib? Yes
Frequency:
60.0 Hz
Frequency:
60.0 Hz
Figure 3-10 Generator Metering Menu
