Emission Compliant Systems
32 690 03 Rev. I KohlerEngines.com
Remove Inlet Screen
Inlet Components
A
B
C
A Secondary Air Valve Assembly B Barb C Inlet Screen
1. Remove inlet screen from secondary air valve assembly by grasping inlet screen at base and gently pulling away
from valve assembly.
2. Use a soft brush to remove debris from screen.
3. Run water through inlet screen in reverse direction.
4. To reinstall, push inlet screen onto barb of secondary air valve assembly. An audible click will be heard when inlet
screen is properly reinstalled.
