1. Install the Faucet
NOTE: Handle orientation
is designed to be on the right.
Partially thread the screws into the ring.
Insert the faucet through the mounting surface.
Slide the washer up on the shank.
Thread the ring up the shank until it is 1/4 ″ (6 mm) from the underside of the sink.
Turn the ring so the screws align front and back.
Use a Phillips screwdriver to tighten the screws.
Escutcheon
ጎ߃
Washer
ۈං
Ring
ۨ࿋࣍
1/4"
(6 mm)
Shank
ც࠶
Ҿጎୄཀྵ
ጀᅪǖդݛၠᆌሞׂᆸ௬ă
൩அີฎฎۨ࿋࣍ాă
൩ୄཀྵ֭Ҿጎ௬ă
ሞ௬ူࢾී࠶ླྀୄཀྵLjԍࢺቸۥዿც࠶ă
൩ۈංࣂႊ߇ă
൩֣ٗڹူۨ࿋࣍ᄂႊ߇ฉ1/4” (6 mm)ă
ገۯۨ࿋࣍๑அີኟ௬ࢅԝ௬ܔጚă
൩ᆩๆጴஅີژஅີă
ࢾීླྀ࣮ࢾීۥዿୄཀྵă
Extend the spray into the basin, from under the deck push the spray hose up until the
protective cap is against the shank, but no further.
Push the pullout hose back until the spray is against the spout.
