Kohler BANCROFT User Manual

-4-
2.
A.
()
2. Surface mounting the cabinet on a wall.
NOTE:
A. Install Mounting Bar.
Installing the cabinet on a wall without the door attached can
make installing easier for one person. Do not mount the doors
until the boxes is in or on the wall.
(Step one varies on type of cabinet
you have, see below.)
1) For Single Door
Drill two 3/16 holes in bottom mounting bar at indent location.
Use the supplied anchors or locate studs if possible.
1)
5
K-3892T
K-3893T
4 1/2" from edge side of cabinet
114
K-3893T
3/4" bottom of Cabinet
20
Fig. 3 3
K-3892T
2" bottom of Cabinet
50
2) For Double Door
Drill three 3/16 holes in bottom mounting bar at indent
location. Use the supplied anchors or locate studs if possible.
2)
5
Fig. 4 4
2" from edge side of cabinet
50
3/4 bottom of cabinet
20
K-15239T
3) Drill 1/4 hole in wall for mounting bar anchors at locations
shown in Fig.3.(If you do not use the anchor, drill a 3/32
pilot hole.) After the holes are drilled, fit the mounting bar
of the single door onto wall by referring to Fig.3 and fit the
mounting bar of the double door onto wall by referring to
Fig.4.
3) 3 7
(2)
34
1159769-T01-A
