Governor System
4324 690 06 Rev. P KohlerEngines.com
Speed Control Input
A
A
A
A Red Wire with Yellow Tracer.
This connection is either a single wire red with yellow
tracer or a 6 pin connector body with a red wire with
yellow tracer.
GCU Designs
A
B
C
D
E
F
C
D
C
D
A First Design GCU B Second Design GCU
C Green LED Light D Yellow LED Light
E Third Design GCU F
Fourth (Latest) Design
GCU

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kohler CH680 and is the answer not in the manual?

Kohler CH680 Specifications

General IconGeneral
Displacement674 cc
Compression Ratio8.5:1
Fuel SystemCarburetor
Ignition SystemElectronic
Cooling SystemAir-cooled
StarterElectric
Engine Type4-cycle, overhead valve (OHV)
Oil Capacity1.9 L (2.0 U.S. qt)
LubricationFull Pressure
Power22 hp (16.4 kW) at 3600 rpm
