10.6
Section 10
Inspection and Reconditioning
Normal: Even after long hours of operation a valve can
be reconditioned and reused if the face and margin are
in good shape. If a valve is worn to where the margin is
less than 1/32" do not reuse it. The valve shown was in
operation for almost 1000 hours under controlled test
conditions.
Bad Condition: The valve depicted here should be
replaced. Note the warped head; margin damaged and
too narrow. These conditions could be attributed to
excessive hours or a combination of poor operating
conditions.
Leakage: A poor grind on face or seat of valve will
allow leakage resulting in a burned valve on one side
only.
Coking: Coking is normal on intake valves and is not
harmful. If the seat is good, the valve could be reused
after cleaning.
