Kohler Command PRO CH735 Service Manual

Specifi cations
1924 690 01 Rev. K KohlerEngines.com
CLEARANCE
SPECIFICATIONS
3
ECH630-ECH680 ECH730-ECH749 CH26 CH735 CH745
Piston, Piston Rings, and Piston Pin (Style A continued)
Top Compression Ring-to-
Groove Side Clearance 0.050/0.095 mm (0.0019/0.0037 in.) 0.025/0.048 mm (0.0010/0.0019 in.)
Middle Compression Ring-to-
Groove Side Clearance 0.030/0.075 mm (0.0012/0.00307 in.) 0.015/0.037 mm (0.0006/0.0015 in.)
Oil Control Ring-to-Groove Side
Clearance 0.010/0.011 mm (0.0004/0.0043 in.) 0.026/0.176 mm (0.0010/0.0070 in.)
Top and Center Compression
Ring End Gap
New Bore 0.25/0.56 mm (0.0100/0.0224 in.)
Used Bore (Max.) 0.80 mm (0.0315 in.) 0.94 mm (0.037 in.)
Thrust Face O.D.
7
79.943/79.961 mm
(3.1473/3.1480 in.)
82.949/82.967 mm (3.2657/3.2664 in.)
Max. Wear Limit 79.816 mm
(3.1423 in.)
82.822 mm (3.2606 in.)
Piston Thrust Face-to Cylinder
Bore
7
Running Clearance
New 0.039/0.082 mm (0.0015/0.0032 in.)
Piston Style B
Piston-to-Piston Pin Running
Clearance 0.006/0.017 mm (0.0002/0.0007 in.)
Pin Bore I.D.
New
Max. Wear Limit
17.006/17.012 mm (0.6695/0.6698 in.)
17.025 mm (0.6703 in.)
Pin O.D.
New
Max. Wear Limit
16.995/17.000 mm (0.6691/0.6693 in.)
16.994 mm (0.6691 in.)
Top Compression Ring-to-
Groove Side Clearance 0.030/0.070 mm (0.001/0.0026 in.)
Middle Compression Ring-to-
Groove Side Clearance 0.030/0.070 mm (0.001/0.0026 in.)
Oil Control Ring-to-Groove Side
Clearance 0.060/0.190 mm (0.0022/0.0073 in.)
Top Compression Ring End Gap
New Bore
0.100/0.279 mm
(0.0039/0.0110 in.) 0.189/0.277 mm (0.0074/0.0109 in.)
Used Bore (Max.) 0.490 mm
(0.0192 in.)
0.531 mm (0.0209 in.)
Middle Compression Ring End
Gap
New Bore
1.400/1.679 mm
(0.0551/0.0661 in.) 1.519/1.797 mm (0.0598/0.0708 in.)
Used Bore (Max) 1.941 mm
(0.0764 in.)
2.051 mm (0.0808 in.)
Thrust Face O.D.
New 79.966 mm
(3.1483 in.)
8
82.978 mm (3.2668 in.)
7
Max. Wear Limit 79.821 mm
(3.1426 in.)
8
82.833 mm (3.2611 in.)
7
Piston Thrust Face-to Cylinder
Bore Running Clearance
New
0.025/0.068 mm
(0.0010/0.0027 in.)
8
0.019/0.062 mm (0.0007/0.0024 in.)
7
3
Values are in Metric units. Values in parentheses are English equivalents.
7
Measure 6 mm (0.2362 in.) above bottom of piston skirt at right angles to piston pin.
8
Measure 13 mm (0.5118 in.) above bottom of piston skirt at right angles to piston pin.
