Specifi cations
8 24 690 34 Rev. DKohlerEngines.com
TORQUE SPECIFICATIONS
3,5
CH682 CH732 CH742 CH752
Oil Sentry
™
Pressure Switch 4.5 N·m (40 in. lb.)
Solenoid (Starter)
Mounting Hardware 4.0-6.0 N·m (35-53 in. lb.)
Nut, Positive (+) Brush Lead 8.0-11.0 N·m (71-97 in. lb.)
Speed Control Bracket
Fastener 10.7 N·m (95 in. lb.) into new holes
7.3 N·m (65 in. lb.) into used holes
Starter Assembly
Thru Bolt 5.6-9.0 N·m (49-79 in. lb.)
Mounting Screw 15.3 N·m (135 in. lb.)
Brush Holder Mounting Screw 2.5-3.3 N·m (22-29 in. lb.)
Stator
Mounting Screw 6.2 N·m (55 in. lb.)
Valve Cover
Yellow O-Ring Style Cover Fastener
w/Integral Metal Spacers 6.2 N·m (55 in. lb.)
CLEARANCE SPECIFICATIONS
3
CH682 CH732 CH742 CH752
Camshaft
End Play 0.076/0.127 mm (0.0030/0.0050 in.)
Running Clearance 0.025/0.063 mm (0.0010/0.0025 in.)
Bore I.D.
New
Max. Wear Limit
20.000/20.025 mm (0.7874/0.7884 in.)
20.038 mm (0.7889 in.)
Bearing Surface O.D.
New
Max. Wear Limit
19.962/19.975 mm (0.7859/0.7864 in.)
19.959 mm (0.7858 in.)
Connecting Rod
Connecting Rod-to-Crankpin Running Clearance
New
Max. Wear Limit
0.030/0.055 mm (0.0012/0.0022 in.)
0.070 mm (0.0028 in.)
Connecting Rod-to-Crankpin Side Clearance 0.26/0.63 mm (0.0102/0.0248 in.)
Connecting Rod-to-Piston Pin Running Clearance 0.015/0.028 mm (0.0006/0.0011 in.)
Piston Pin End I.D.
New
Max. Wear Limit
17.015/17.023 mm (0.6699/0.6702 in.)
17.036 mm (0.6707 in.)
Crankcase
Governor Cross Shaft Bore I.D.
New
Max. Wear Limit
8.025/8.075 mm (0.3159/0.3179 in.)
8.088 mm (0.3184 in.)
3
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
