15
Specifi cations
14 690 12 Rev. -- KohlerEngines.com
TORQUE SPECIFICATIONS
3,6
CV173 CV200 CV224
Finger Guard (as equipped)
Rear Guard Fastener 10 N·m (89 in. lb.)
Side Guard Fastener (Muffl er Side, Carburetor Side) 9.5 N·m (84 in. lb.)
Flywheel
Retaining Nut 51.5 N·m (38 ft. lb.)
Fuel Tank (if equipped)
Lower Tank Bracket to Crankcase Screw 8 N·m (71 in. lb.)
Stud 10 N·m (89 in. lb.)
Governor
Lever Fastener 9.5 N·m (84 in. lb.)
Gear Fastener 9.5 N·m (84 in. lb.)
Ignition
Spark Plug 27 N·m (20 ft. lb.)
Module Fasteners (Stud or Screw) 10 N·m (89 in. lb.)
Muffl er
Exhaust Stud 5.0 N·m (44 in. lb.)
Exhaust Nut 9.5 N·m (84 in. lb.)
Barrel Baffl e (CV200, CV224) Screw to Cylinder Head 8 N·m (71 in. lb.)
Oil Pan (torque sequence on page 14)
Fastener 14.7 N·m (130 in. lb.)
Clean Oil Change Screw 14.7 N·m (130 in. lb.)
Oil Drain Plug
7
13.6 N·m (120 in. lb.)
Oil Filter Nipple 28.5 N·m (252 in. lb.)
Oil Pump Screen Cover Fastener 9.5 N·m (84 in. lb.)
Retractable Starter
Fastener 8 N·m (71 in. lb.)
Rocker Arm
Stud 13.6 N·m (120 in. lb.)
Pivot Jam Nut 9.5 N·m (84 in. lb.)
Speed Control
Bracket Assembly Fastener 8 N·m (71 in. lb.)
Valve Cover (torque sequence on page 14)
Fastener 8 N·m (71 in. lb.)
3
Values are in Metric units. Values in parentheses are English equivalents.
6
Lubricate threads with engine oil prior to assembly.
7
Apply thread sealant around three full threads before assembly. No excess sealant allowed on inside or outside of
joint. Threads with preapplied sealant do not require use of additional sealant. Approved sealants include Perma-Loc
LH 150, Perma-Loc MM 115, Perma-Loc HH 120, Perma-Loc HL 126.
