Kohler Command PRO ECH749 Service Manual

8.9
Section 8
Disassembly
8
Figure 8-34. Removing Outer Baffl es.
6. Remove the remaining hex fl ange screws
securing the blower housing. Remove the blower
housing. See Figure 8-35.
Figure 8-36. Removing Oil Sentry™ Lead.
2. Remove the Oil Sentry™ switch from the
breather cover.
NOTE: This is optional. Removing the Oil Sentry™ is
not required to remove the breather cover.
Remove Oil Temperature Sensor
1. Disconnect the lead from the oil temperature
sensor. See Figure 8-37.
5. Remove the outer baffl es. See Figure 8-34.
Figure 8-35. Removing Blower Housing.
Remove Oil Sentry™
1. Disconnect the lead from the Oil Sentry™ switch.
See Figure 8-36.
Figure 8-37. Removing Oil Temperature Sensor
Lead.
2. Remove the oil temperature sensor from the
breather cover.
NOTE: Unless the oil temperature sensor is damaged
or malfunctioning, disassembly from the
breather cover is unnecessary.
3. Remove the breather hose from the breather
cover.
Remove Inner Baffl es and Breather Cover
1. Remove the two hex fl ange screws securing the
inner baffl es to the crankcase.
2. Remove the inner (valley) baffl es. See Figure 8-38.
Figure 8-38. Removing Inner (Valley) Baffl es.

Kohler Command PRO ECH749 Specifications

General

Fuel System	Carburetor
Starter	Electric
Governor Type	Mechanical
Lubrication System	Full Pressure
Fuel Type	Gasoline
Crankshaft Orientation	Horizontal
Bore	3.27 in (83 mm)
Cooling System	Air
Oil Type	SAE 10W-30
Spark Plug Gap	0.030 in (0.76 mm)
Valve Clearance - Intake	0.004 - 0.006 in (0.10 - 0.15 mm)
Crankshaft Type	Varies by model
Crankshaft Thread Size	Varies by model
Crankshaft Length	Varies by model
Crankshaft Diameter	Varies by model
Type	Overhead Valve (OHV)
