三 安装直流电源盒
1. (20)
16
15
17
18
混水
(Mixer)
19
(21)
1. Take battery box out, loosen screws
4节5
单冷
(Cold)
注意：
20
21
2.
2. Connect power cords with
四 如何安装排水组件
4
(22）
22
(23)
Apply plumbers putty
23
(22)
Screw the drain flange ( 22) into drain
body (23). Tighten the locknut (24)
manually from the underside.
Note: Remove excessive putty. Note:
after tightening locknut (24), do not
adjust drain body position, otherwise
putty seal might be damaged.
(24)
(25) (26)
25mm 55mm
Connect the tailpiece( 25) to the
trap(26). The tailpiece should ex tend
25mm to 55mm into the trap.
Note:
Ensure cylinder install on water inlet.
Install DC Power Unit
(20), insert 4 AA batteries per +/-
pole indication ( 21) on battery
box cover. Fasten battery box
cover with screws.
Note: no reversed battery
polarity. Do not mix new and used
batteries together.
corresponding color wires, then place
battery box assembly to empty space
within control assembly then fasten
control box by screws based on
installation direction. For AC faucet,
except corresponding cords connect to
AC/DC transformer output, other
installation methods are identical.
