HOW TO CHANGE TO A MIXING SENSOR
FAUCET
(If customerpurchases t
ee inlet
a
ssy. 1298710-SP)
三通
进水
软管组件
用户自备角阀 外螺纹
如何转换成混水感应龙头
若用户另购三通进水软管
组件1298710-SP
1. ( )
0.5mm
2
0.3
mm
2
m
2.
1.
AC power unit (sticker on the back) should be
installed in a dry place away from water. Customer
should prepare wire tube and wire according to their
requirement. Wire tube should be mounted into the wall.
Suggested wire: AC connection wire adopts wires with
protecting layer or sleeve and the section should
be ≥ 0.5mm . The section of DC connection wire
should be ≥ 0.3mm . The connection pattern must
follow the illustrations above.
2.After wire layout finished, check and repair if needed.
Then connect AC connector to AC connector within
FPC pipe, DC connect or (black-orange) on electrical
box to faucet power cord connector (wire from valve
box). Finally t urn on AC power source.The faucet will
work this period.
( )
AC
AC
DC
Tee , Inlet Assy
8
1359742-T01-A
2
2
工作状态。
