Section 7 Decision-Makerr 6000 ControllerTP-6356 4/12
Status Event
or Fault
User-Defined
Settings
Time
Delay
(sec.)
Inhibit
Time
Delay
(sec.)
Default
Selection
Range Setting
Relay
Driver
Output
(RDO)
Digital Display
Refer
to
Menu
Starter ’B’ 10 STARTER ’B’
FAILURE
Not adjustable
Starting Aid
(see Time Delay
Starting Aid)
—
Sync TImeout 10, 16 SYNC
TIMEOUT
60 sec.
delay
0--600
System Ready 10 RDO-1
(lead 60)
Not adjustable
Time Delay Engine
Cooldown (TDEC)
8, 10 DELAY ENG
COOLDOWN
RDO-4
(lead 70C)
00:00--10:00
min:sec
5:00
Time Delay Engine
Start (TDES)
8, 10 DELAY ENG
START
RDO-15 00:00--5:00
min:sec
00:00
Time Delay Starting
Aid
8, 10 RDO-16 0--10 sec. 0:00
Underfrequency 7, 10 UNDER
FREQUENCY
80%--100% 97% FAA
80%
10
Undervoltage
Shutdown
7, 8,
10
UNDER
VOL TAGE
70%--100% 70%
30-sec time
delay
5--30
Weak Battery 10 WEAK
BATTERY
Fixed 60% of
nominal
2
* DD/MTU engine with MDEC/ADEC
[ NFPA applications
] 3x (times) energize time shown in Menu 17
User-Defined Settings
Calibration
Refer
to
Menu
Digital Display Range Setting Default Selection
User-Defined
Settings
Voltage Adjustment 11 VOLT ADJ ±20% of system voltage System voltage
Underfrequency Unload
Frequency Setpoint
11 FREQUENCY SETPOINT 40 to 70 Hz 1 Hz below system freq.
(ECM)
2 Hz below system freq.
(non-ECM)
Underfrequency Unload
Slope
11 SLOPE 0--10% of rated voltage
volts per cycle
3.1% of system
voltage
Reactive Droop 11 VOL TAGE DROOP 0--10% of system voltage 4% of system voltage
Regulator gain or stability 11 REGULATORGAINADJ 1--10000 100
Volts match window 16 VOLTS MATCH WINDOW +/-- 1--10% V +/-- 1.0% V
Volts match gain 16 VOLTS MATCH GAIN 0--99.99 1.00
Volts match reset 16 VOL TS MATCH RESET 0--50 sec. 1.0 sec.
Synch frequency window 16 SYNCH FREQ WINDOW +/-- 0.1--5 Hz +/-- 2.0 Hz
Frequency match gain 16 FREQ MATCH GAIN 0.01 --99.99 1.00
PGEN ID 16 GENERATOR ID 0--8 (0 by reset) 0
No. of PGEN nodes 16 NBROFNODESONBUS 0--8 (0 by reset) 0
Phase match window 16 PHASE MATCH WINDOW +/-- 1.0--20.0 degrees +/-- 5.0 degrees
Phase match gain 16 PHASE MATCH GAIN 0--99.99 1.0
Phase match reset 16 PHASE MATCH RESET 0--50 sec. 1.0 sec.
Dwell time 16 DWELL TIME 0.1--30 sec. 0.3 sec.
First on close time delay 16 FIRST ON CLOSE TD 0.5--10 sec. 0.5 sec.
Fail to switch time delay 16 FAIL TO SYNCH TD 10--600 sec. 300 sec.
Volt/frequency ok timer 16 VOLT_FREQ OK TIMER 0--10 sec. 0.5 sec.
