A. 11
B. 13
C. ( )
NOTE: BELOW FOR1&2DOOR CABINET ONLY*
A. This screw releases the door from the cabinet and allows
up and down adjustment. Fig.12
B. These screws allow you to plumb the door as shown in
Fig.13
C. The screws you use for attaching the hinges.
(Supplied with hinges)
A
B
B
3.
A.
1)
2)
B. 10
C.
D.
E.
3)
3. Attaching Side Kits to a Surface Mounted
Cabinet
A. Apply foam tape to Side kit bracket
DO NOT PEEL RELEASE LINER UNTIL YOU HAVE
TEST FIT THE SIDE KITS ON THE CABINET!
1) Peel tape from sheet, leave liner on.
2) Apply as shown to side kit brackets, be sure they are
clean and dry.
3)
B. Attach the side kit brackets to the cabinet as shown in
Fig.10
C. Test fit the side kits, then cleas the back of the side kits
with rubbing alcohol.
D. Peel the release tape from the brackets and apply the side
kits, push firmly to set.
E. Cover the screw heads with the screw caps.
Align top of side kit with top of flange
#8 x 3/8" screws
self thread into
Side Kit brackets
#8
2 pieces
26" high
660
Side kit bracket
(Fits tight under the
flange of cabinet)
()
Side kit brackets
Fig. 9 9
Fig. 10 10
4.
4. Door adjustments
-7-
Fig. 11 11
8-32 x 1/2" (SS829)
6-32 x 3/8" (SS679)
1056564-T01-A
