Kohler K-16109 - Installation Checkout

1004636-2-A
5
Kohler Co.
Valve Inlet
Nut
Supply
Tube
Supply
Stop
Aerator
Body
Washe
r
Aerator
Chamber
Assembly
3. Supply Installation
- Slip the ground joint nut onto the supply tube.
- Carefully position the round end of the supply tube squarely to the
valve inlet and supply stop.
- Tighten all nuts.
4. Installation Checkout
- Make sure the faucet handles are in the off position.
- Turn on the main water supply (not the faucet), and check for leaks.
- Remove the aerator.
- Turn on the hot and cold faucet handles and run the water for about
aminutetoremoveanydebris.
- Check for leaks.
- Turn the water off, and reattach the aerator.
