5. Install the Control Box
Position the control box 11-1/2" (292 mm) minimum to 12-1/2" (318 mm)
maximum below the deck. Check the Specication Sheet for the control box
location.
Mark the location of the mounting holes.
NOTE: The provided w
all anchors are for concrete wall installation. Use the
appropriate wall anchors depending on your wall material.
Drill the holes per the anchor manufacturers instructions. If using the provided
w
all anchors, drill 1/4” (6 mm) pilot holes.
Aach the control box to the w
all as shown.
Secure with the four screws provided.
1419080-2-A
10 Kohler Co.
