Kohler K-3492 Installation Guide

14. Install the Seat
Position a bolt and washer through each of the three holes in the toilet seat hinge.
Position the gasket on the bolts from the underside of the hinge.
Place a plastic tapered bushing, tapered-side-down, on each of the bolts.
Place an expansion sleeve on each bolt.
Thread a brass tapered bushing, tapered-side-up, onto each bolt. Do not tighten at this time.
Position the seat on the toilet and align the bolts with the toilet seat mounting holes.
Insert the bolts and sleeves into the holes.
Use a flat-blade screwdriver to thread the bolts until they are snug, but do not fully tighten at this
time.
Lower the seat and check seat alignment.
Align the seat on the toilet and then carefully raise the seat to expose the bolts.
Tighten the bolts. Do not overtighten.
Position the tab on the hinge cover with the slot in the hinge assembly and snap the hinge cover
into place.
With the seat raised, gently push the seat cover forward. The seat and seat cover should close
slowly.
Bolt
Brass Tapered
Bushing
Expansion Sleeve
Plastic Tapered
Bushing
Washer
Toilet
Toilet Seat
Mounting Hole
Hinge
Cover
Gasket
Hinge
Cover Tab
Hinge
Slot
Hinge
Cover/Seat
Kohler Co. 13 1035530-2-C
