9. Install the Collar
Place the wiring harness plug, level switch wire, and refill tube on the floor so they extend out the
rear access opening.
Tape them to the floor so they will not be pinched or damaged.
Install the collar onto the tank.
Clip the spray shield into place over the fill valve.
Tape
Level
Switch
Wire
Electrical
Plug
Centerline
Refill Tube
Wiring Harness Plug
Spray Shield
Collar
Tank
Kohler Co. 9 1035530-2-C
