Kohler K-45210 - K-45209;K-45210 Model Dimensions

Roughing-In
Backing
Material
3-3/4"
(95 mm)
27"
(686 mm)
18-5/8" (473 mm)
18-5/8" (473 mm)
9-1/2"
(241 mm)
75" (1905 mm)
Recommended
72" (1829 mm)
Minimum
80" (2032 mm)
Recommended
75" (1905 mm)
Minimum
Backing
Material
6" (152 mm)
Minimum
27"
(686 mm)
6" (152 mm)
Minimum
K-45210 (Less Showerhead, Handshower, and Hose)
K-45209 (Less Showerhead, Handshower, and Hose)
Kohler Co. 5 1213116-2-A
