7. Complete the Installation
If an interface is not available, proceed to the ″Installation Checkout″ section, and ″Checking the Valve
Installation without an Installed Interface.″
NOTICE: Do not plug in the power cord until all interface cables are connected.
NOTE: Make drip loops in all cables and cords.
Route the interface cable(s) in the wall from the valve location to the interface installation locations.
If not already installed, install the interface(s) at this time according to the instructions packed with
the product.
Connect the interface cable(s) to the valve.
Verify there is power to the 120 V GFCI electrical outlet.
Plug the power cord into the outlet.
Slide the split boot onto the
interface cable.
Split Boot
Solid Boot
1145587-2-A 12 Kohler Co.
