4. Install the Electrical Outlet
NOTICE: Do not install the valve under a whirlpool surround or in any location where the temperature
may reach temperatures over 104°F (40°C). The valve and its integrated power supply are rated to operate
in temperatures up to 104°F (40°C).
Install a 120 V GFCI electrical outlet, within the stud framing, in close proximity to the valve. Locate
the outlet above the valve allowing ample space to mount the valve in close proximity to the
outlet.
Place outlet higher
than valve.
Drip Loop
Power Cord
Kohler Co. 9 1145587-2-A
