Fig.#16
Fig.#15
Close by rotating the handle clockwise and open by
rotating the handle counterclockwise
Handle of tee valve
Tee valve
Decorative cover
J.
2.
Install Tee Valve.
IMPORTANT!
1.
Dimensions in the pictures are for reference only.
Please install deco cover on tee valve before installation.
NOTE: Do not reuse the old tee valve.
Unit: mm
1.
Connect the water outlet.
2.
Open the shut-off valve.
NOTE:Please use the water supply hose accompanying with new machine. The old hose assembly shall not be used
again.
K.
Connect the Water
IMPORTANT!The supplied hose must be used for this installation.
150 10
250 10
To Next Page
