TP-7070 8/2014 Section 1 Specifications and Features
1. APM802 controller human-machine interface (HMI)
2. Emergency stop switch
3. Key switch
4. Manual start/stop button
5. 240 VAC / 60 Hz power supply connection (required)
6. Terminal block TB10 for accessory connections
7. Wiring harness connection
8. USB ports, qty. 2 (on the back of the HMI)
9. Controller touchscreen
10. Fault indicator/display button
11. Mode selection switch
12. Generator set electrical values
13. Generator set mechanical data
1
9
12
10
13
7
11
2
11601000945
Note: Covers have been removed for illustration.
6
5
8
Human-Machine Interface (HMI)
3
4
Figure 1-1 A
PM802 Controller and Customer Connection Box
