DISASSEMBLY/REASSEMBLY

Clean the ltering element with air blast. Air must be blown

frominsidetooutsidethecartridgeatadistanceofatleast15

cmfromthepaper.

Lightly and repeatedly tap the element on a hard surface to

eliminateallexcessdirt.

Openaircleaner(g.4).

Unscrewthewingnut1(g.4a)andremovethelterelement(g.5).

ChecktherubbersealisundamagedA(g.5a)

Cleanthelteringelementwithairblast.

Ifthelteringelementhasbeenalreadycleanedothertimes,orifitis

irreparablyclogged,throwitawayandreplace.

RettheairlterandmakesurethesealAisproperlyinserted,then

tightenthewingnut1.

Makesurethatthelterismountedinthecorrectwayother-

wise dust and other impurities could illtrate into the intake

ducts.

Prelter for dry air lter

Removeandcleanthepre-lterifclogged.
