Kohler KDI 2504 TCRE5 User Manual

2
TECHNICAL INFORMATION
EN 12
2 TECHNICAL INFORMATION
2.1 General description of the engine
- 4-stroke, in-line cylinders Diesel engine; - Liquid-cooling system;
- 4 valves per cylinder with hydraulic tappets;
- Turbocharger with Waste-gate valve;
- Common rail - Direct injection.
2.2 Engine specifications
Tab. 2.1
TECHNICAL DATA
UNIT OF
MEASURE
Engine type
KDI 1903 TCR KDI 2504 TCR
Cylinders
n.
3
4
Bore
mm
88
88
Stroke
mm
102
102
Displacement
cm
3
1861
2482
MAX INCLINATION DURING OPERATION
(even in combined)
α
30° max. 30 minutes
α
35° max.1 minute
OIL CAPACITY (MAX
level.) including oil filter
standard
version
lt. 8.9 11.5
with balancer
device
lt. - 9
DRY WEIGHT
Kg 233
267
2.3 Engine dimensions (mm)
