TECHNICAL INFORMATION
MANUFACTURER SPECIFICATIONS AND OPERATION
GENERAL INFORMATION
UNIT OF
MEASURE
KDI 3404 TM
Operating cycle diesel - 4-stroke
Cylinders No. 4
Bore x stroke mm 96x116
Displacement cm
3
3359
Compression ratio 17:1
Intake Supercharged with Turbocharger
Cooling Liquid
Crankshaft rotation (view from ywheel side) Counterclockwise
Combustion sequence 1-3-4-2
Timing System
Valves per cylinder 4
Timing System Rods and rocker arms - Camshaft in the crankcase
Tappets Hydraulic
Injection Direct
Engine dry weight Kg 394
MAX inclination 30' continuous operation α 40°
MAX inclination 1' continuous operation α 45°
POWER AND TORQUE
GENERAL INFORMATION
UNIT OF
MEASURE
KDI 3404 TM
MAX. operating speed Rpm 2400
MAX. operating power
(ISO TR 14396 - SAE J1995 - CE 97/68)
kW 100
Maximum torque (at 1500 rpm) Nm 500
CONSUMPTIONS
GENERAL INFORMATION
UNIT OF
MEASURE
KDI 3404 TM
Specic fuel consumption (best point) g/kWh 205
Oil consumption %Fuel < 0.1
FUEL SUPPLY SYSTEM
GENERAL INFORMATION
UNIT OF
MEASURE
KDI 3404 TM
Type of fuel Diesel UNI-EN590 - ASTM D975
High-pressure fuel injection pump STANADYNE - DB
Fuel supply Low pressure electric pump
Fuel lter
Filtering surface cm
2
2300
Degree of ltration µm 5
Maximum pressure at injection pump inlet bar 0.2
LUBRICATION CIRCUIT
2.1 Engine specications

Kohler KDI 3404 TM Specifications

General

Brand	Kohler
Model	KDI 3404 TM
Category	Engine
Language	English
