-- SCHEMATIC SHOWING TYPICAL "8ELOW WATER" MARINE COOLING SYSTEM
Belt Tension:
On marine models, the belt should be adjusted so that it can be depressed about’ l/P as
shown in accompanying illustration.
To adjust, remove belt guard, loosen adjusting plate capscrews
then shift plate until proper tension is obtained-
retightening plate at new setting then replace belt
guard.
ENGINE WATER '
ADJUSTING VI\-
FIGURE 6-7 --
BELT ADJUSTMENT - MARINE
EXHlUJST
OPENING
EXHAUST
PIPE
l-3/4 0
WATER
LINE
FROM
MANIFOLD
FIGURE 6-8 --
EXHAUST MIXER - MARINE MODELS
