Kohler OnCue Plus Wireless Kit User Manual

TT-1618 6/14 15
Additional Information
LED Operation
Power
Green On = System On
Green Off = System Off
Amber Blinking = WLAN Activity
LAN
Off = No Ethernet
On = Connection Established
Blinking = Sending, Receiving
WLAN
(AP Mode)
Off = WLAN Disabled
On = WLAN Enabled
Blinking = WLAN Activity
WLAN
(Client Mode)
Off = WLAN Disabled
Green Blinking = Good Connection
Yellow blinking = Acceptable Quality
Red Blinking = Poor Connection
Internal Antenna Electrical Specifications
Antenna shape Patch array
RF frequency band 2.4 -- 2.5 GHz
Power handling 2W
Impedance 50 Ohms
VSWR Less than 2.0
Polarization Linear (vertical)
Antenna Gain Peak gain 2.45 GHz 8.45 dBi
Vertical HPBW 113_
Horizontal HPBW 39_
