Connect the Wires (cont.)
NOTE: Setup must be completed within 10 minutes.
When the Connector Status LED illuminates red, the system is
ready for mobile app setup.
If the Connector Status LED is flashing red, unplug the power
cord to reset the system.
When the Connector Status LED is flashing red and green, the
system is setting up.
When the Connector Status LED illuminates green, the system is
ready for use.
If the Connector Status LED is flashing green, the router
connection was lost. Verify that the router is powered on and
within range.
If the Connector Status LED does not illuminate green, an
electronics reset is needed.
Electronics Reset
Open the handle to turn the faucet on.
Wave a hand over the sensor to turn the faucet off.
Close the handle.
Repeat the above steps 10 times in 1 minute to clear the profile
information. If the above sequence is broken the count will reset
to zero.
Kohler Co. 9
1387795-2-B
