Kohler XT650 - Disassembly, Inspection, and Service; External Engine Components and Initial Disassembly

33
Disassembly/Inspection and Service
14 690 01 Rev. G KohlerEngines.com
WARNING
Before working on engine or equipment, disable engine as
follows: 1) Disconnect spark plug lead(s). 2) Disconnect
negative (–) battery cable from battery.
Accidental Starts can cause severe injury or
death.
Disconnect and ground spark plug lead(s)
before servicing.
External Engine Components
F
G
E
D
A
K
C
B
J
H
I
K
J
H
L
H
J
L
K
A
Engine Cover and
Insert
B Engine Cover C
Engine Cover and
Retractable Start
D Retractable Starter
E Blower Housing F Mufer Guard G Mufer H Air Cleaner Base
I Breather Hose J Paper Element K Air Cleaner Cover L Precleaner
