The electrical ratings for your air conditioner are listed on the
model and serial number label. The model and serial number
label is located behind the front panel above the coil area.
Specific electrical requirements are listed in the chart below.
Follow the requirements for the type of plug on the power supply
cord.
P ower s upply cord Wiring requirements
127 volt (103.5 min. -126.5 max.)
0-
15
a
mps
15-amp time-delay fuse or
circuit breaker
Use on single outlet circuit
only.
220 volt (198 min. - 242 max.)
0-
15a
mps
15-amp time-delay fuse or
circuit breaker
Use on single outlet circuit only.
0-
15a
mps
15-amp time-delay fuse or
circuit breaker
Use on single outlet circuit only.
To get the maximum cooling efficiency,the air conditioner is
designed to splash the condensate on the condenser coil. If the
splashing sound annoys you, you can provide an outside drain
no use of draining water)
1
. Remove the rubber plug from the body base plate.
2. F
ix the drain water head to the chassis, and place the gasket
Drain water
by using the following procedure, which may however cause a
small loss of performance.
on it. And install them with 2 screws -Figure 2. (Figure 1 for
Figure 1
Figure 2
Drain water head 1
2 screws
3
. Connect the drain water head 2 to the drain water head 1
1. Drain hose or tubing can be purchased locally to satisfy your
2. It is possible to connect the drain hose to the outlet without
Note:
(Figure 3)
Figure 3
particular needs.
the drain pan.
Drain water head 2
230 volt(207min.-253max.)
230 volt(193min.-253max.) (GJC06BK-D3NMNE2A)
