I General
I.1 About this manual
This manual forms part of the complete documentation for the digifas™ 7200 series of servo
amplifiers. It describes the assembly, installation and commissioning of the standard units of
this series, i.e. the versions of the servo amplifier without a CONNECT module.
It also includes advice about transport, storage, maintenance and disposal of the equipment.
Other parts of the complete documentation of the digifas™ 7200 series:
— Installation / operation instructions for the PC-operator software:
BS7200 for digifas™ 7200 series Order no. 83107
— technical description of the digital interfaces to automation systems:
BIT CONNECT for digifas™ 7200-SPS series Order no. 83108
PROFIBUS CONNECT for digifas™ 7200-L2/DP series Order no. 83106
PULSE CONNECT for digifas™ 7200-STEP series Order no. 83109
CAN CONNECT for digifas™ 7200-CAN series Order no. 83105
All the necessary documentation for the particular version of the unit is delivered together with
the servo amplifier.
This manual makes the following demands on the technical staff:
I.2 Prescribed usage of the servo amplifiers
Use the digifas™ 7200 series of servo amplifiers only on a three-phase 400V industrial earthed
mains supply to amplifier a synchronous servo-motor from the 6SM series.
The servo amplifier may only be operated in a closed switch cabinet, taking into account the
environmental requirements which are defined in Chapter I.8.1.
The digifas™ 7200 series of servo amplifiers are exclusively intended for driving the 6SM
series of brushless synchronous servo-motors under speed or torque control.
The servo amplifiers are installed as components of electrical equipment or machines and may
only be operated as integral components of such equipment.
Prepare a hazard analysis of your machine.
Chapter I General Page I - 1
digifas
®
7200 series 03.98
Transport : only by personnel with knowledge of the handling of electrostatic
sensitive devices.
Installation : only by personnel with training in electrical engineering.
Commissioning : only by personnel with extensive knowledge of the fields of
electrical engineering and amplifier technology.
Only if the system components as described in Chapter VI.2 are used and the rules for
installation in this documentation (Chapter II.1 ff) are followed, we guarantee the
confomance of the servo amplifiers with the following standards for industrial areas:
EC EMC Directive 89/336/EEC
EC Low Voltage Directive 73/23/EEC
