Kolver EDU2AE User Manual

Vers. 260918 2
EDU 2AE and EDU 2AE/HP
RO
power supply and control units are an innovative system for controlling the
torque of any current control MITO and PLUTO electric screwdrivers: MITO15, PLUTO 3, PLUTO 6,
PLUTO 10, PLUTO 15, PLUTO 20, PLUTO 35 snd PLUTO50, either inline, pistol, for automation and
with angle head (only PLUTO). It’s also possible to use the following clutch models: PLUTO 3FR/HS,
PLUTO 5FR and PLUTO 7FR.
EDU 2AE and EDU 2AE/HP
RO
deliver all the advantages of precision torque control electric tools at a
fraction of the price of transdurized tools.
The state-of-the-art electronic control circuit cuts the power supply to the motor calculating the correct
torque in response to 3 parameters; voltage, frequency and current, according to the selected options.
The AC 90÷260V - 50÷60Hz power supply is converted into 40VDC required by the PLUTO series
screwdrivers through a switching board.
Model
Torque
(Nm)
Speed (rpm)
Min
Max
MITO15
0,2-1,5
450
850
PLUTO 3
0,5-3
370
1300
PLUTO 6
0,85-6
200
850
PLUTO 10
1,5-10
110
600
PLUTO 15
2-15
60
320
PLUTO 20
3-20
50
200
PLUTO 35
3-35
40
140
PLUTO 50
5-50
20
90
PLUTO 6 ANG
0,7-6
200
850
PLUTO 8 ANG
1,5 - 7
110
600
PLUTO 15 ANG
2-15
100
320
PLUTO 20 ANG
3-18
60
200
PLUTO 25 ANG
3-22
40
140
PLUTO 3FR/HS
0,5-2,5
1550
2400
PLUTO 5FR
0,7-5
600
1000
PLUTO 7FR
1,5-7
350
600
IMPORTANT: EDU 2AE and EDU 2AE/HP
RO
are highly accurate units but it is critically important
to select the correct options to ensure that proper torque is being applied. Read the menu description
carefully and in case of doubt please contact Kolver for support information.
Turn the unit on through the on/off switch on the back panel. The unit will carry a general system check and
“waiting connection” will appear on the last line of the display. If the connection with the motor control
board is successful the following screen will be displayed:
K
o
l
v
e
r
S
.
r
.
l
.
E
D
U
2
A
E
V
e
r
s
i
o
n
2
.
0
0
l
o
a
d
i
n
g
.
.
.
