Komatsu D39EX-21 - Page 219

MAINTENANCE SERVICE PROCEDURE
4-39
(8) Frame center ball (1 place)
(9) Rod pin (2 places)
q D39EX,PX
(1) Lift cylinder bottom pin (2 places)
(2) Lift cylinder head pin (2 places)
(3) Angle cylinder bottom pin (2 places)
(4) Frame mounting pin (2 places)
(5) Angle cylinder head pin (2 places)
(6) Tilt cylinder head pin (1 place)
(7) Tilt cylinder bottom pin (1 place)
(8) Frame center ball (1 place)
(9) Rod pin (2 places)
