20-101-1 PC09-1
TESTING AND ADJUSTING
TOOLS FOR TESTING, ADJUSTING, AND TROUBLESHOOTING
Measurement item
Symbol
Part No. Part Name Q’ty Remarks
Engine speed A 799-203-9000 Multi-tachometer 1
Exhaust color B
1 799-201-9000 Handy smoke checker 1
Discoloration 0 – 70 %
(with standard color)
(
Discoloration ×1/10 Bosch index
)
2
Commercially
available
Smoke meter 1
Valve clearance C
Commercially
available
Thickness gauge 1
Compression pressure D
1 795-502-1205 Compression gauge 1
2 795-111-1120 Adapter 1
Engine oil pressure E
1
799-101-5002
Oil pressure gauge KIT
(Analog)
1
Pressure gauge: 2.5, 5.9, 39.2, 58.8 MPa
{25, 60, 400, 600 kg/cm
2
}
790-261-1203
Oil pressure gauge KIT
(Digital)
1
Pressure gauge: 58.8 MPa {600 kg/cm
2
}
2 799-401-2320 Oil pressure gauge 1
Pressure gauge: 0.98 MPa {10 kg/cm
2
}
Work equipment, swing,
travel circuit oil pressure
F
799-101-5002
Oil pressure gauge KIT
(Analog)
1
Pressure gauge: 2.5, 5.9, 39.2, 58.8 MPa
{25, 60, 400, 600 kg/cm
2
}
790-261-1203
Oil pressure gauge KIT
(Digital)
1
Pressure gauge: 58.8 MPa {600 kg/cm
2
}
Oil leakage inside hydrau-
lic cylinder
G
Commercially
available
Cylinder 1
Operating effort H
79A-264-0021 Push-pull scale 1 0 – 294 N {0 – 30 kg}
79A-264-0091 Push-pull scale 1 0 – 490 N {0 – 50 kg}
Stroke, hydraulic drift J
Commercially
available
Scale 1
Work equipment speed K
Commercially
available
Stopwatch 1
Voltage resistance L
Commercially
available
Tester 1
Sensor, wiring harness M 799-601-7400 T-adapter KIT 1
➀
TOOLS FOR TESTING, ADJUSTING,
AND TROUBLESHOOTING
