132
LUBRICATION
4.5.3
LUBRICA
TION DIAGRAM PC15R
IMPORTANT
☞
•
For the lubrication proc
edures for the single points, see
“
4.7 MAINTENANC
E PLAN
”.
•
The type of
lubricant to be used is indic
ated in the lubr
ica
nt table (See
“
4.3 FUEL, COOLANT AND LU-
BRICANTS
”
).
2000 h
1000 h
250 h
100 h
50 h
10 h
RW
A06700
Hydraulic oil
Grease
Engine oil
T
ransmissio
n oil
133
135
