2-20
PC210/240-ENG
11.4 CONTROL LEVERS, PEDALS
1. SAFETY LOCK LEVER
WARNING
• When leaving the operator’s compartment, set the safety lock
lever securely to the LOCK position. If the control levers are
not locked, and they are touched by mistake, this may lead to
a serious accident.
If the safety lock lever is not placed securely in the LOCK
position, the control levers may not be properly locked. Check
that the situation is as shown in the diagram.
• When the safety lock lever is raised, take care not to touch the
work equipment control lever. If the safety lock lever is not
properly locked at the upper position, the work equipment and
swing will move, creating a potentially dangerous situation.
• When the safety lock lever is lowered, take care not to touch
the work equipment control lever.
11. EXPLANATION OF COMPONENTS
