HOW TO READ THIS MANUAL
HOW TO READ THIS MANUAL
Outline
This chapter explains how to read the procedures of "removal,
disassembly, assembly, inspection, and adjustment" and "trouble-
shooting".
Definition of Terms
CAUTION:
• An item or a work procedure, neglect of which can cause a
death or a serious injury if neglected.
• An item or a work procedure to be observed especially
among those, neglect of which can cause an injury, an
accident, or a damage of the vehicle or component parts.
Reference : Supplementary explanation for the ease of work.
Standard value : Permissible deviation of a value at inspection or
adjustment.
Limit value : The maximum or minimum which a value must not
exceed at inspection or adjustment.
Definition of Units
In this manual, tightening torque, pressure, etc. are indicated by the
"SI unit" (International unit) first, then by the "metric unit) in { }.
Example) Tightening torque: 59 - 78 Nm {6.0 - 8.0 kgf•m}
SI unit {Metric unit}
*1. Conventional unit may be used in SI.
CONVERSION OF MAJOR UNITS
Quantity SI unit Conventional unit Coefficient of conversion into SI
Acceleration
m/s
2
G 9.80665
Torque and moment Nm kgf•m 9.80665
Force N kgf 9.80665
Pressure MPa
kgf/cm
2
0.09809665
kPa mmHg 0.133322
Power/Power efficiency kW PS 0.735499
W kcal/h 1.16279
Volume
cm
3
cc 1
Spring constant N/mm kgf/mm 9.80665
Fuel consumption g/kW•h(*1) g/PS•h 1.3596
