OPERATION
EXPLANATION OF COMPONENTS
MAIN POWER SWITCH
Use
the
switch
(1)
to
turn
the
main
power
of
the
air
conditioner
ON/OFF.
When
the
switch
is
pressed,
display
monitor
(A)
lights
up.
The
fan
begins
operation.
When
the
switch
is
pressed
again,
the
air
conditioner
is
turned
OFF
and
the
display
monitor
goes
out. The
fan
stops.
(When
the
switch
is
turned
ON,
the
setting
displayed
is
the
same
as
when
the
air
conditioner
was
turned
OFF.)
3 - 85
