1007D Altimeter Operators Manual 974-72007001/1.0
Installation Page 17
Kongsberg Mesotech Ltd.
Port Coquitlam, BC - Canada
and maximum range. With the system in the water and
pointed toward the bottom, turn on the power and confirm
the following:
The output reading corresponds to the water depth.
The output reading is steady.
The output reading decreases as the unit is lowered.
Note that the unit must be lowered by at least as much as
the current resolution of the altimeter to see a change.
3.4 Deployment
The Model 1007D altimeter is designed to operate in depths
up to 3000 meters. To prevent improper operation and/or
damage to the unit, protect the transducer face from contact
with any surface or foreign object.
The 1007D's standard aluminum housing is anodized to
prevent corrosion. However, for extended immersion in salt
water, it may be necessary to use sacrificial zinc anodes.
3.5 Maintenance
The only routine maintenance required for the 1007D
altimeter is to keep the transducer face clean using mild
detergent.
The unit should only be opened by qualified personnel at the
factory or authorized service center. Any attempt to do
otherwise will void the warranty. Contact the factory for
repair or replacement of faulty or damaged units.
